What can be done with ZEG?
Wireless Portable Scale [ZEG] Introduction Video
Features
1.Language and display unit are selectable
Standard Japanese/English multi-language display is supported by default. Switching the display is easily done by the user, and the print format changes according to the display language. In addition to the standard kg display, pounds (lb) display is also selectable*. Correction for gravitational acceleration is also possible according to the country or region of use.
2.For items of various shapes and sizes
By arranging four pads according to the purpose and usage of measurement, it becomes possible to measure objects of any size.
3.Dust and water resistance equivalent to IP66
ZEG scale achieves a dust-proof and waterproof performance equivalent to EC standard IP66* by adopting appropriate structures, eliminating the operation section, and adopting non-contact charging technology. This significantly improves durability and enables weighing in the rain or of moist objects. *According to our company’s tests
4.Visualization of balance and weight distribution
The wireless multi-indicator scale with printer (MS-07Z) is equipped with the latest E Ink display. It allows real-time display and understanding of the weight of each pad. The E Ink display features wide viewing angles, high contrast, and low power consumption. The display achieves readability similar to writing on paper even in direct sunlight.
5.The ease of portability
By the small and lightweight pads that are easily installable and movable by anyone, ZEG achieves the ability to ‘weigh wherever you want’. Even with the large capacity type ZEG-04W, it weighs only 17kg/pad. Despite this, it can measure a fully loaded 40ft high cube container.
Dimensions
Specificataions
| Model | Maximum Capacity | Readability | Platform Size(W×L×H)mm | Body Weight | Power Source | Battery Life |
|---|---|---|---|---|---|---|
| ZEG-03W-01 | 1t | 1kg | 300(W)×110(L)×58(H) | approx. 4.3kg/PAD | Lithium-ion rechargeable battery | approx. 400 hours |
| ZEG-03W-03 | 3t | 1kg | ||||
| ZEG-04W-05 | 5t | 1kg | 415(W)×373(L)×59(H) | approx. 17kg/PAD |
||
| ZEG-04W-10 | 10t | 10kg |
